Name: Township Range Section Rancho Boundaries

Display Field: LABEL

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN STYLE="font-weight:bold;">Background</SPAN></P><P><SPAN STYLE="font-style:italic;">PLSS (from wikipedia)</SPAN></P><P><SPAN>The Public Land Survey System (PLSS) is the surveying method used historically over the largest fraction of the United States to survey and spatially identify land parcels before designation of eventual ownership, particularly for rural, wild or undeveloped land. It is sometimes referred to as the rectangular survey system (although non rectangular methods such as meandering can also be used).</SPAN></P><P><SPAN STYLE="font-style:italic;">Ranchos</SPAN></P><P><SPAN>The Spanish and, later, Mexican governments encouraged settlement of territory now known as California by the establishment of large land grants called ranchos, from which the English word ranch is derived. Land-grant titles (concessions) were government-issued, permanent, unencumbered property-ownership rights to land called ranchos.</SPAN></P><P><SPAN STYLE="font-style:italic;">Why this dataset?</SPAN></P><P><SPAN>This dataset was created in order to integrate the boundaries from two different datasets – a Rancho Boundary file from the Bureau of Land Management (BLM), and a parcel-accurate Township Range Section file created by the LA County Department of Public Works. There are many sources of this data out there, but the rancho are holes in the PLSS datasets and the TRS is a hole in the rancho files. This combines both of those.</SPAN></P><P><SPAN STYLE="font-style:italic;">Method of conflation</SPAN></P><P><SPAN>These two datasets were combined, and any holes and overlaps were conflated to match the Rancho boundaries that were created by BLM. When there were questions I used the USGS topographic quad sheets to verify numbering and naming. </SPAN></P></DIV></DIV></DIV>

Copyright Text: Los Angeles County Public Works, Mapping & GIS Services (mapping@dpw.lacounty.gov)

Default Visibility: false

MaxRecordCount: 1000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 6275511.358962595
YMin: 1715032.8802506775
XMax: 6668480.769216418
YMax: 2122082.800073087
Spatial Reference: 102645  (2229)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: TYPE
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: RANCHO
  Label: Rancho
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [0, 0, 0, 0]
  Outline:
  Style: esriSLSSolid
  Color: [0, 197, 255, 255]
  Width: 2
• Value: SECTION
  Label: TRS
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [0, 0, 0, 0]
  Outline:
  Style: esriSLSSolid
  Color: [255, 0, 0, 255]
  Width: 1
Transparency: 0
Labeling Info:
Label Placement: esriServerPolygonPlacementAlwaysHorizontal
Label Expression: [LANDGRANT]
Use Coded Values: true
Symbol:
Color: [0, 132, 168, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Arial
Font Style: normal
Font Weight: bold
Font Decoration: none

Min. Scale: 288896.0
Max. Scale: 0.0
Label Placement: esriServerPolygonPlacementAlwaysHorizontal
Label Expression: [TOWNSHIP] CONCAT "-" CONCAT [RANGE] CONCAT "-" CONCAT [SECTION]
Use Coded Values: true
Symbol:
Color: [230, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 9
Font Family: Tahoma
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 36113.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• LABEL ( type: esriFieldTypeString, alias: LABEL, length: 50 )
• TWN ( type: esriFieldTypeString, alias: TWN, length: 20 )
• RNG ( type: esriFieldTypeString, alias: RNG, length: 20 )
• SEC ( type: esriFieldTypeString, alias: SEC, length: 20 )
• TYPE ( type: esriFieldTypeString, alias: TYPE, length: 30 )
• MAP_LINK ( type: esriFieldTypeString, alias: MAP_LINK, length: 254 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
